Connecting Tomorrow's Network Today
CAT6 UTP LAN Cable
Premium Performance. Reliable Connectivity.
INTRODUCTION
The Q-FLX CAT 6 UTP LAN Cable is a premium grade network cable with Solid Copper designed for professional durability.
Built with a solid, bare copper conductor of 99.99% purity and 101% electrical conductivity, insulated with high-density polyethylene insulation for Stable data transmission and signal Integrity.
Generally Complies with ANSI/TIA 568C.2 Standards.
CONSTRUCTION
01
Conductor
23 AWG Solid Bare Annealed Electrolytic Grade Copper.
02
Insulation
High Density Polyethylene (HDPE).
03
Cross Filler
High Density Polyethylene.
04
Pairs
4 Pairs Twisted Construction.
05
Outer Sheath
ST-1 FR PVC.
06
Outer Diameter
5.9 ± 0.20 mm.
PACKING
Available in Tangle free coils of Packing Length 305 meters.
Engineered For Performance
Reliable transmission, superior signal integrity and consistent network performance.
COLOR IDENTIFICATION
| Pair | Color |
|---|---|
| Pair 1 | Orange White / Orange Stripe |
| Pair 2 | Blue White / Blue Stripe |
| Pair 3 | Brown White / Brown Stripe |
| Pair 4 | Green White / Green Stripe |
ELECTRICAL PERFORMANCE
| PROPERTY | VALUE |
|---|---|
| Operating Voltage | 72 KV |
| Max. D.C Cond. Resistance at 20°C | 93.8 Ohm/km |
| Characteristic Impedance | 100 ± 15% Ω |
| Mutual Capacitance | < 5.6 nF/100m |
| Capacitance Unbalance | 330 pF/100m Max |
| Insulation Resistance | 100 M Ohm/km |
| Dielectric Strength | 1.0KV DC or 0.75KV AC for 1 Min |
| Propagation Delay Skew | 45 nS/100m |
| Resistance Unbalance | 5% Max |
| Return Loss | 8 dB @ 250 MHz |
| Normal Velocity of Propagation | < 69% (Nominal) |
APPLICATIONS
Office
Networks
Home
Networking
CCTV &
Surveillance
LAN
Infrastructure
Commercial
Facilities
Data
Communication Systems
